Ambient Operating Temperature | 60°F (15.56°C) |
Amps | 2.4 |
Bearing Type | Ball |
CSA Listing | YES |
Capacitor MFD (µF) | 7.5 |
Duty | Continuous |
Full Load Amps | 2 |
Motor HP | 1/3 HP |
Motor Type | PSC (Permanent Split Capacitor) |
Mounting | Base, Stud, Strap |
NEMA Frame | 48 |
Number of Speeds | 1 (Single) |
RPM | 1075 |
Rotation | Reversible |
Shaft Diameter | 1/2" |
Shaft Length | 6 |
Voltage | 208-230 VAC |
